| Outer diameter (D1): 65 ± 2,0 (mm) |
| Inner diameter (D2): 50 ± 2,0 (mm) |
| Pitch: 17 ± 1,0 (mm) |
| Standard length per coil: 100 (m) |
| Minimum bending radius: 200 (mm) |
| Standard outer diameter and height of coil: 1,17 x 0,45 (m) |
Loading...
BFP 50
| Outer diameter (D1): 65 ± 2,0 (mm) |
| Inner diameter (D2): 50 ± 2,0 (mm) |
| Pitch: 17 ± 1,0 (mm) |
| Standard length per coil: 100 (m) |
| Minimum bending radius: 200 (mm) |
| Standard outer diameter and height of coil: 1,17 x 0,45 (m) |
